CDS-John Blue - Piston Pump - NGP-6055-HY Series - single piston double acting - 21.0 GPM - 120 PSI rated pressure

CDS-John Blue Piston Pump

NGP-6055-HY

CDS-John Blue double action single piston pumps are the most reliable liquid fertilizer sytems on the market today.  The fixed stroke of the NGP-6055-HY pump has a rated flow of 21.0 GPM with a rated pressure of 120 PSI.  Rated speed is 550 RPM's on this NGP-6055-HY single piston-double action CDS-John Blue Pump.  This specific pump has a 1.5 inch inlet and outlet with 220 series flanges optional. When this pump is coupled with a flow divider you are guaranteed even application rated from this reliable NGP-6055-HY CDS-John Blue piston pump. All standard Piston Pumps are cast iron and manufactured with Viton Piston Packings and Buna O-rings and rod packings. Most commonly used with liquid fertilizers that have a pH greater than 5 and standard herbicides that are compatible with Buna and Viton. Application rates will not change due to temperature fluctuations.  All CDS-John Blue pumps are built to last, and engineered for performance.
