CDS-John Blue - Piston Pump - NGP-7055-HYF Series - single piston double acting - 34.2 GPM - 120 PSI rated pressure
JBLNGP7055HYFCDS-John Blue - Piston Pump - NGP-7055-HYF Series - single piston double acting - 34.2 GPM - 120 PSI rated pressure
CDS-John Blue Piston Pump
NGP-7055-HYF
CDS-John Blue double action single piston pumps are the most reliable liquid fertilizer systems on the market today. The fixed stroke of the NGP-7055-HYF pump has a rated flow of 34.2 GPM with a rated pressure of 120 PSI. Rated speed is 550 RPM's on this NGP-7055-HYF single piston-double action CDS-John Blue Pump. This specific pump has a 1.5" inlet and outlet, with 220 series flanges. When this pump is coupled with a flow divider you are guaranteed even application rated from this reliable NGP-7055-HYF CDS-John Blue piston pump. All standard Piston Pumps are cast iron and manufactured with Viton Piston Packings and Buna O-rings and rod packings. Most commonly used with liquid fertilizers that have a pH greater than 5 and standard herbicides that are compatible with Buna and Viton. Application rates will not change due to temperature fluctuations.
Options:
- Pump with flanges. Add "-F" after model part number (i.e., NGP-7055-F).
- Pump less the sprocket. Add "-K" after model part number (i.e., NGP-7050-K).
- RC40 chain 18 tooth sprocket. Add "-R" after model part number (i.e., NGP-7050-R).
- 316SS wet-end castings. Add "-S" after model part number (i.e., NGP-7050-S).
- Viton wet-end o-rings and rod packing. Add "-U" after model part number (i.e., NGP-7050-U).
Accessories:
- 115670 - Manual Clutch Add-On - NGP Universal
- 115671 - Hydraulic Clutch Add-On - NGP Universal
- 115672 - Electric Clutch Add-On - NGP Universal
- 115674 - Stainless Wet-End Conversion - NGP-7050 Series
- 116000-01 - 1 1/2" NPT to 200 Series Flange Adapter, Ductile Iron
- 116000-01S - 1 1/2" NPT to 200 Series Flange Adapter, Stainless Steel
